Datos del producto
| Item number | Name | Downloads |
|---|---|---|
| 170000 | HTsafeEM Pipe with 1 socket DN/OD 32 x 150 mm | |
| 170010 | HTsafeEM Pipe with 1 socket DN/OD 32 x 250 mm | |
| 170020 | HTsafeEM Pipe with 1 socket DN/OD 32 x 500 mm | |
| 170040 | HTsafeEM Pipe with 1 socket DN/OD 32 x 1000 mm | |
| 170050 | HTsafeEM Pipe with 1 socket DN/OD 32 x 1500 mm | |
| 170060 | HTsafeEM Pipe with 1 socket DN/OD 32 x 2000 mm | |
| 170070 | HTsafeEM Pipe with 1 socket DN/OD 32 x 3000 mm | |
| 170080 | HTsafeGL Pipe without socket DN/OD 32 x 5000 mm | |
| 170100 | HTsafeB Bend DN/OD 32 15° | |
| 170110 | HTsafeB Bend DN/OD 32 30° | |
| 170120 | HTsafeB Bend DN/OD 32 45° | |
| 170130 | HTsafeB Bend DN/OD 32 67,5° | |
| 170140 | HTsafeB Bend DN/OD 32 87,5° | |
| 170200 | HTsafeEA Branch DN/OD 32/32 45° | |
| 170300 | HTsafeEA Branch DN/OD 32/32 67,5° | |
| 170400 | HTsafeEA Branch DN/OD 32/32 87,5° | |
| 170500 | HTsafeU Coupler DN/OD 32 | |
| 170510 | HTsafeMM Double Socket DN/OD 32 | |
| 170620 | HTsafeM Plug DN/OD 32 | |
| 171000 | HTsafeEM Pipe with 1 socket DN/OD 40 x 150 mm | |
| 171010 | HTsafeEM Pipe with 1 socket DN/OD 40 x 250 mm | |
| 171020 | HTsafeEM Pipe with 1 socket DN/OD 40 x 500 mm | |
| 171030 | HTsafeEM Pipe with 1 socket DN/OD 40 x 750 mm | |
| 171040 | HTsafeEM Pipe with 1 socket DN/OD 40 x 1000 mm | |
| 171050 | HTsafeEM Pipe with 1 socket DN/OD 40 x 1500 mm | |
| 171060 | HTsafeEM Pipe with 1 socket DN/OD 40 x 2000 mm | |
| 171070 | HTsafeEM Pipe with 1 socket DN/OD 40 x 3000 mm | |
| 171080 | HTsafeGL Pipe without socket DN/OD 40 x 5000 mm | |
| 171100 | HTsafeB Bend DN/OD 40 15° | |
| 171110 | HTsafeB Bend DN/OD 40 30° | |
| 171120 | HTsafeB Bend DN/OD 40 45° | |
| 171130 | HTsafeB Bend DN/OD 40 67,5° | |
| 171140 | HTsafeB Bend DN/OD 40 87,5° | |
| 171200 | HTsafeEA Branch DN/OD 40/40 45° | |
| 171300 | HTsafeEA Branch DN/OD 40/40 67,5° | |
| 171400 | HTsafeEA Branch DN/OD 40/40 87,5° | |
| 171500 | HTsafeU Coupler DN/OD 40 | |
| 171510 | HTsafeMM Double Socket DN/OD 40 | |
| 171620 | HTsafeM Plug DN/OD 40 | |
| 171710 | HTsafeR Reducer, eccentric DN/OD 40/32 | |
| 171800 | HTsafeL Long Socket DN/OD 40 | |
| 171900 | HTsafeS Siphon connection piece to metal and plastic DN/OD 40/40 | |
| 171910 | HTsafeSW Angled siphon connection piece to metal and plastic DN/OD 40/30 | |
| 171920 | HTsafeSW Angled siphon connection piece to metal and plastic DN/OD 40/40 | |
| 172000 | HTsafeEM Pipe with 1 socket DN/OD 50 x 150 mm | |
| 172010 | HTsafeEM Pipe with 1 socket DN/OD 50 x 250 mm | |
| 172020 | HTsafeEM Pipe with 1 socket DN/OD 50 x 500 mm | |
| 172030 | HTsafeEM Pipe with 1 socket DN/OD 50 x 750 mm | |
| 172040 | HTsafeEM Pipe with 1 socket DN/OD 50 x 1000 mm | |
| 172050 | HTsafeEM Pipe with 1 socket DN/OD 50 x 1500 mm | |
| 172060 | HTsafeEM Pipe with 1 socket DN/OD 50 x 2000 mm | |
| 172070 | HTsafeEM Pipe with 1 socket DN/OD 50 x 3000 mm | |
| 172080 | HTsafeGL Pipe without socket DN/OD 50 x 5000 mm | |
| 172100 | HTsafeB Bend DN/OD 50 15° | |
| 172110 | HTsafeB Bend DN/OD 50 30° | |
| 172120 | HTsafeB Bend DN/OD 50 45° | |
| 172130 | HTsafeB Bend DN/OD 50 67,5° | |
| 172140 | HTsafeB Bend DN/OD 50 87,5° | |
| 172200 | HTsafeEA Branch DN/OD 50/50 45° | |
| 172210 | HTsafeEA Branch DN/OD 50/40 45° | |
| 172300 | HTsafeEA Branch DN/OD 50/50 67,5° | |
| 172310 | HTsafeEA Branch DN/OD 50/40 67,5° | |
| 172400 | HTsafeEA Branch DN/OD 50/50 87,5° | |
| 172410 | HTsafeEA Branch DN/OD 50/40 87,5° | |
| 172500 | HTsafeU Coupler DN/OD 50 | |
| 172510 | HTsafeMM Double Socket DN/OD 50 | |
| 172600 | HTsafeRE Inspection Pipe DN/OD 50 | |
| 172620 | HTsafeM Plug DN/OD 50 | |
| 172710 | HTsafeR Reducer, eccentric DN/OD 50/40 | |
| 172715 | HTsafeR Reducer DN/OD 50/40 short | |
| 172720 | HTsafeR Reducer, eccentric DN/OD 50/32 | |
| 172800 | HTsafeL Long Socket DN/OD 50 | |
| 172810 | HTsafeAM Single Socket with gasket DN/OD 50 | |
| 172820 | HTsafeUG Connection piece to cast-iron pipe DN/OD 50 | |
| 172900 | HTsafeDA Double Branch DN/OD 50/50/50 67,5° | |
| 172910 | HTsafeS Siphon connection piece to metal and plastic DN/OD 50/40 | |
| 172920 | HTsafeS Siphon connection piece to metal and plastic DN/OD 50/50 | |
| 172940 | HTsafeSW Angled siphon connection piece to metal and plastic DN/OD 50/40 | |
| 172950 | HTsafeSW Angled siphon connection piece to metal and plastic DN/OD 50/50 | |
| 172970 | HTsafeDSW Double Siphon Bend DN/OD 40/50/40 | |
| 173000 | HTsafeEM Pipe with 1 socket DN/OD 75 x 150 mm | |
| 173010 | HTsafeEM Pipe with 1 socket DN/OD 75 x 250 mm | |
| 173020 | HTsafeEM Pipe with 1 socket DN/OD 75 x 500 mm | |
| 173030 | HTsafeEM Pipe with 1 socket DN/OD 75 x 750 mm | |
| 173040 | HTsafeEM Pipe with 1 socket DN/OD 75 x 1000 mm | |
| 173050 | HTsafeEM Pipe with 1 socket DN/OD 75 x 1500 mm | |
| 173060 | HTsafeEM Pipe with 1 socket DN/OD 75 x 2000 mm | |
| 173070 | HTsafeEM Pipe with 1 socket DN/OD 75 x 3000 mm | |
| 173080 | HTsafeGL Pipe without socket DN/OD 75 x 5000 mm | |
| 173100 | HTsafeB Bend DN/OD 75 15° | |
| 173110 | HTsafeB Bend DN/OD 75 30° | |
| 173120 | HTsafeB Bend DN/OD 75 45° | |
| 173130 | HTsafeB Bend DN/OD 75 67,5° | |
| 173140 | HTsafeB Bend DN/OD 75 87,5° | |
| 173200 | HTsafeEA Branch DN/OD 75/75 45° | |
| 173210 | HTsafeEA Branch DN/OD 75/50 45° | |
| 173300 | HTsafeEA Branch DN/OD 75/75 67,5° | |
| 173310 | HTsafeEA Branch DN/OD 75/50 67,5° | |
| 173400 | HTsafeEA Branch DN/OD 75/75 87,5° | |
| 173410 | HTsafeEA Branch DN/OD 75/50 87,5° | |
| 173500 | HTsafeU Coupler DN/OD 75 | |
| 173510 | HTsafeMM Double Socket DN/OD 75 | |
| 173600 | HTsafeRE Inspection Pipe DN/OD 75 | |
| 173620 | HTsafeM Plug DN/OD 75 | |
| 173710 | HTsafeR Reducer, eccentric DN/OD 75/50 | |
| 173715 | HTsafeR Reducer DN/OD 75/50 short | |
| 173800 | HTsafeL Long Socket DN/OD 75 | |
| 173810 | HTsafeAM Single Socket with gasket DN/OD 75 | |
| 173820 | HTsafeUG Connection piece to cast-iron pipe DN/OD 75 | |
| 173900 | HTsafeDA Double Branch DN/OD 75/75/75 67,5° | |
| 174000 | HTsafeEM Pipe with 1 socket DN/OD 90 x 150 mm | |
| 174010 | HTsafeEM Pipe with 1 socket DN/OD 90 x 250 mm | |
| 174020 | HTsafeEM Pipe with 1 socket DN/OD 90 x 500 mm | |
| 174030 | HTsafeEM Pipe with 1 socket DN/OD 90 x 750 mm | |
| 174040 | HTsafeEM Pipe with 1 socket DN/OD 90 x 1000 mm | |
| 174050 | HTsafeEM Pipe with 1 socket DN/OD 90 x 1500 mm | |
| 174060 | HTsafeEM Pipe with 1 socket DN/OD 90 x 2000 mm | |
| 174070 | HTsafeEM Pipe with 1 socket DN/OD 90 x 3000 mm | |
| 174080 | HTsafeGL Pipe without socket DN/OD 90 x 5000 mm | |
| 174100 | HTsafeB Bend DN/OD 90 15° | |
| 174110 | HTsafeB Bend DN/OD 90 30° | |
| 174120 | HTsafeB Bend DN/OD 90 45° | |
| 174130 | HTsafeB Bend DN/OD 90 67,5° | |
| 174140 | HTsafeB Bend DN/OD 90 87,5° | |
| 174200 | HTsafeEA Branch DN/OD 90/90 45° | |
| 174210 | HTsafeEA Branch DN/OD 90/75 45° | |
| 174220 | HTsafeEA Branch DN/OD 90/50 45° | |
| 174400 | HTsafeEA Branch DN/OD 90/90 87,5° | |
| 174410 | HTsafeEA Branch DN/OD 90/75 87,5° | |
| 174420 | HTsafeEA Branch DN/OD 90/50 87,5° | |
| 174500 | HTsafeU Coupler DN/OD 90 | |
| 174510 | HTsafeMM Double Socket DN/OD 90 | |
| 174600 | HTsafeRE Inspection Pipe DN/OD 90 | |
| 174620 | HTsafeM Plug DN/OD 90 | |
| 174710 | HTsafeR Reducer, eccentric DN/OD 90/75 | |
| 174720 | HTsafeR Reducer, eccentric DN/OD 90/50 | |
| 174730 | HTsafeR Reducer DN/OD 90/50 short | |
| 174800 | HTsafeL Long Socket DN/OD 90 | |
| 174900 | HTsafeDA Double Branch DN/OD 90/90/90 87,5° (swept) | |
| 175000 | HTsafeEM Pipe with 1 socket DN/OD 110 x 150 mm | |
| 175010 | HTsafeEM Pipe with 1 socket DN/OD 110 x 250 mm | |
| 175020 | HTsafeEM Pipe with 1 socket DN/OD 110 x 500 mm | |
| 175030 | HTsafeEM Pipe with 1 socket DN/OD 110 x 750 mm | |
| 175040 | HTsafeEM Pipe with 1 socket DN/OD 110 x 1000 mm | |
| 175050 | HTsafeEM Pipe with 1 socket DN/OD 110 x 1500 mm | |
| 175060 | HTsafeEM Pipe with 1 socket DN/OD 110 x 2000 mm | |
| 175070 | HTsafeEM Pipe with 1 socket DN/OD 110 x 3000 mm | |
| 175080 | HTsafeGL Pipe without socket DN/OD 110 x 5000 mm | |
| 175100 | HTsafeB Bend DN/OD 110 15° | |
| 175110 | HTsafeB Bend DN/OD 110 30° | |
| 175120 | HTsafeB Bend DN/OD 110 45° | |
| 175130 | HTsafeB Bend DN/OD 110 67,5° | |
| 175140 | HTsafeB Bend DN/OD 110 87,5° | |
| 175200 | HTsafeEA Branch DN/OD 110/110 45° | |
| 175210 | HTsafeEA Branch DN/OD 110/75 45° | |
| 175220 | HTsafeEA Branch DN/OD 110/50 45° | |
| 175230 | HTsafeEA Branch DN/OD 110/90 45° | |
| 175300 | HTsafeEA Branch DN/OD 110/110 67,5° | |
| 175310 | HTsafeEA Branch DN/OD 110/75 67,5° | |
| 175320 | HTsafeEA Branch DN/OD 110/50 67,5° | |
| 175400 | HTsafeEA Branch DN/OD 110/110 87,5° | |
| 175410 | HTsafeEA Branch DN/OD 110/75 87,5° | |
| 175420 | HTsafeEA Branch DN/OD 110/50 87,5° | |
| 175430 | HTsafeEA Branch DN/OD 110/90 87,5° | |
| 175500 | HTsafeU Coupler DN/OD 110 | |
| 175510 | HTsafeMM Double Socket DN/OD 110 | |
| 175600 | HTsafeRE Inspection Pipe DN/OD 110 | |
| 175620 | HTsafeM Plug DN/OD 110 | |
| 175700 | HTsafeR Reducer, eccentric DN/OD 110/90 | |
| 175705 | HTsafeR Reducer DN/OD 110/90 short | |
| 175710 | HTsafeR Reducer, eccentric DN/OD 110/75 | |
| 175715 | HTsafeR Reducer DN/OD 110/75 short | |
| 175720 | HTsafeR Reducer, eccentric DN/OD 110/50 | |
| 175725 | HTsafeR Reducer DN/OD 110/50 short | |
| 175740 | HTsafeSA Plug-in Branch DN/OD 110/110 87,5° | |
| 175750 | HTsafeSM Plug-in Socket DN/OD 110/110 | |
| 175760 | HTsafeRI Inner Reducer DN/OD 110/75 | |
| 175770 | HTsafeRI Inner Reducer DN/OD 110/50 | |
| 175800 | HTsafeL Long Socket DN/OD 110 | |
| 175810 | HTsafeAM Single Socket with gasket DN/OD 110 | |
| 175820 | HTsafeUG Connection piece to cast-iron pipe DN/OD 110 | |
| 175900 | HTsafeDA Double Branch DN/OD 110/110/110 67,5° | |
| 175910 | HTsafeDA Double Branch DN/OD 110/50/50 67,5° | |
| 175920 | HTsafeED Double Corner Branch DN 110/110/110 67,5° | |
| 175930 | HTsafeDA Double Branch DN/OD 110/110/110 87,5° (swept) | |
| 176000 | HTsafeEM Pipe with 1 socket DN/OD 125 x 150 mm | |
| 176010 | HTsafeEM Pipe with 1 socket DN/OD 125 x 250 mm | |
| 176020 | HTsafeEM Pipe with 1 socket DN/OD 125 x 500 mm | |
| 176030 | HTsafeEM Pipe with 1 socket DN/OD 125 x 750 mm | |
| 176040 | HTsafeEM Pipe with 1 socket DN/OD 125 x 1000 mm | |
| 176050 | HTsafeEM Pipe with 1 socket DN/OD 125 x 1500 mm | |
| 176060 | HTsafeEM Pipe with 1 socket DN/OD 125 x 2000 mm | |
| 176070 | HTsafeEM Pipe with 1 socket DN/OD 125 x 3000 mm | |
| 176080 | HTsafeGL Pipe without socket DN/OD 125 x 5000 mm | |
| 176100 | HTsafeB Bend DN/OD 125 15° | |
| 176110 | HTsafeB Bend DN/OD 125 30° | |
| 176120 | HTsafeB Bend DN/OD 125 45° | |
| 176140 | HTsafeB Bend DN/OD 125 87,5° | |
| 176200 | HTsafeEA Branch DN/OD 125/125 45° | |
| 176210 | HTsafeEA Branch DN/OD 125/110 45° | |
| 176400 | HTsafeEA Branch DN/OD 125/125 87,5° | |
| 176410 | HTsafeEA Branch DN/OD 125/110 87,5° | |
| 176500 | HTsafeU Coupler DN/OD 125 | |
| 176510 | HTsafeMM Double Socket DN/OD 125 | |
| 176600 | HTsafeRE Inspection Pipe DN/OD 125 | |
| 176620 | HTsafeM Plug DN/OD 125 | |
| 176710 | HTsafeR Reducer, eccentric DN/OD 125/110 | |
| 177000 | HTsafeEM Pipe with 1 socket DN/OD 160 x 150 mm | |
| 177010 | HTsafeEM Pipe with 1 socket DN/OD 160 x 250 mm | |
| 177020 | HTsafeEM Pipe with 1 socket DN/OD 160 x 500 mm | |
| 177030 | HTsafeEM Pipe with 1 socket DN/OD 160 x 750 mm | |
| 177040 | HTsafeEM Pipe with 1 socket DN/OD 160 x 1000 mm | |
| 177050 | HTsafeEM Pipe with 1 socket DN/OD 160 x 1500 mm | |
| 177060 | HTsafeEM Pipe with 1 socket DN/OD 160 x 2000 mm | |
| 177070 | HTsafeEM Pipe with 1 socket DN/OD 160 x 3000 mm | |
| 177080 | HTsafeGL Pipe without socket DN/OD 160 x 5000 mm | |
| 177100 | HTsafeB Bend DN/OD 160 15° | |
| 177110 | HTsafeB Bend DN/OD 160 30° | |
| 177120 | HTsafeB Bend DN/OD 160 45° | |
| 177140 | HTsafeB Bend DN/OD 160 87,5° | |
| 177200 | HTsafeEA Branch DN/OD 160/160 45° | |
| 177210 | HTsafeEA Branch DN/OD 160/110 45° | |
| 177400 | HTsafeEA Branch DN/OD 160/160 87,5° | |
| 177410 | HTsafeEA Branch DN/OD 160/110 87,5° | |
| 177500 | HTsafeU Coupler DN/OD 160 | |
| 177510 | HTsafeMM Double Socket DN/OD 160 | |
| 177600 | HTsafeRE Inspection Pipe DN/OD 160 | |
| 177620 | HTsafeM Plug DN/OD 160 | |
| 177700 | HTsafeR Reducer, eccentric DN/OD 160/125 | |
| 177710 | HTsafeR Reducer, eccentric DN/OD 160/110 | |
| 178020 | HTsafeDM Pipe with 2 sockets DN/OD 32 x 500 mm | |
| 178040 | HTsafeDM Pipe with 2 sockets DN/OD 32 x 1000 mm | |
| 178050 | HTsafeDM Pipe with 2 sockets DN/OD 32 x 1500 mm | |
| 178060 | HTsafeDM Pipe with 2 sockets DN/OD 32 x 2000 mm | |
| 178070 | HTsafeDM Pipe with 2 sockets DN/OD 32 x 3000 mm | |
| 178120 | HTsafeDM Pipe with 2 sockets DN/OD 40 x 500 mm | |
| 178140 | HTsafeDM Pipe with 2 sockets DN/OD 40 x 1000 mm | |
| 178150 | HTsafeDM Pipe with 2 sockets DN/OD 40 x 1500 mm | |
| 178160 | HTsafeDM Pipe with 2 sockets DN/OD 40 x 2000 mm | |
| 178170 | HTsafeDM Pipe with 2 sockets DN/OD 40 x 3000 mm | |
| 178220 | HTsafeDM Pipe with 2 sockets DN/OD 50 x 500 mm | |
| 178240 | HTsafeDM Pipe with 2 sockets DN/OD 50 x 1000 mm | |
| 178250 | HTsafeDM Pipe with 2 sockets DN/OD 50 x 1500 mm | |
| 178260 | HTsafeDM Pipe with 2 sockets DN/OD 50 x 2000 mm | |
| 178270 | HTsafeDM Pipe with 2 sockets DN/OD 50 x 3000 mm | |
| 178320 | HTsafeDM Pipe with 2 sockets DN/OD 75 x 500 mm | |
| 178340 | HTsafeDM Pipe with 2 sockets DN/OD 75 x 1000 mm | |
| 178350 | HTsafeDM Pipe with 2 sockets DN/OD 75 x 1500 mm | |
| 178360 | HTsafeDM Pipe with 2 sockets DN/OD 75 x 2000 mm | |
| 178370 | HTsafeDM Pipe with 2 sockets DN/OD 75 x 3000 mm | |
| 178420 | HTsafeDM Pipe with 2 sockets DN/OD 90 x 500 mm | |
| 178440 | HTsafeDM Pipe with 2 sockets DN/OD 90 x 1000 mm | |
| 178450 | HTsafeDM Pipe with 2 sockets DN/OD 90 x 1500 mm | |
| 178460 | HTsafeDM Pipe with 2 sockets DN/OD 90 x 2000 mm | |
| 178470 | HTsafeDM Pipe with 2 sockets DN/OD 90 x 3000 mm | |
| 178520 | HTsafeDM Pipe with 2 sockets DN/OD 110 x 500 mm | |
| 178540 | HTsafeDM Pipe with 2 sockets DN/OD 110 x 1000 mm | |
| 178550 | HTsafeDM Pipe with 2 sockets DN/OD 110 x 1500 mm | |
| 178560 | HTsafeDM Pipe with 2 sockets DN/OD 110 x 2000 mm | |
| 178570 | HTsafeDM Pipe with 2 sockets DN/OD 110 x 3000 mm | |
| 178620 | HTsafeDM Pipe with 2 sockets DN/OD 125 x 500 mm | |
| 178640 | HTsafeDM Pipe with 2 sockets DN/OD 125 x 1000 mm | |
| 178650 | HTsafeDM Pipe with 2 sockets DN/OD 125 x 1500 mm | |
| 178660 | HTsafeDM Pipe with 2 sockets DN/OD 125 x 2000 mm | |
| 178670 | HTsafeDM Pipe with 2 sockets DN/OD 125 x 3000 mm | |
| 179970 | Floortrap HT Safe DN 110 | |
| 880007 | Lip seal DN 32 (HT) | |
| 880017 | Lip seal DN 40 (HT) | |
| 880027 | Lip seal DN 50 (HT Safe) | |
| 880037 | Lip seal DN 75 (HT Safe) | |
| 880047 | Lip seal DN 90 (HT/Skolan) | |
| 880057 | Lip seal DN 110 (HT Safe) | |
| 880077 | Lip seal DN 125 (HT) | |
| 880087 | Lip seal DN 160 (HT) | |
| 880217 | NBR Lip seal oil resistant DN 40 (HT) | |
| 880227 | NBR Lip seal oil resistant DN 50 (HT) | |
| 880237 | NBR Lip seal oil resistant DN 75 (HT) | |
| 880247 | NBR Lip seal oil resistant DN 90 (HT/Skolan) | |
| 881005 | GA gasket (cast iron) DN 50 | |
| 881015 | GA gasket (cast iron) DN 75 | |
| 881200 | HTGM Gasket DN 40/30 A | |
| 881210 | HT/Skolan GM Gasket DN 40/30 B | |
| 881220 | HT/Skolan GM Gasket DN 40/40 C | |
| 881230 | HTGM Gasket DN 40/50/1 1/4 | |
| 881240 | HTGM Gasket DN 50/30 D | |
| 881250 | HTGM Gasket DN 50/40 E | |
| 881260 | HTGM Gasket DN 50/50 F | |
| 881309-07 | Rubber nipple for metal or lead pipes DN 40 1 1/4'' | |
| 881319-07 | Rubber nipple for metal or lead pipes DN 50 1 1/2'' | |
| 881329-07 | Rubber nipple for metal or lead pipes DN 50 1 1/4'' | |
| 881500 | Pull-out protection DN 50 (HT) | |
| 881510 | Pull-out protection DN 75 (HT) | |
| 881540 | Pull-out protection DN 125 (HT) | |
| 881590 | Pull-out protection DN 32 (HT Safe) | |
| 881595 | Pull-out protection DN 40 (HT Safe) |
| Item number | Name | Downloads |
|---|---|---|
| 559000 | HTEM Pipe with socket DN/OD 32 x 150 mm – white | |
| 559010 | HTEM Pipe with socket DN/OD 32 x 250 mm – white | |
| 559020 | HTEM Pipe with socket DN/OD 32 x 500 mm – white | |
| 559030 | HTEM Pipe with socket DN/OD 32 x 1000 mm – white | |
| 559040 | HTEM Pipe with socket DN/OD 32 x 2000 mm – white | |
| 559060 | HTEM Pipe with socket DN/OD 40 x 150 mm – white | |
| 559070 | HTEM Pipe with socket DN/OD 40 x 250 mm – white | |
| 559080 | HTEM Pipe with socket DN/OD 40 x 500 mm – white | |
| 559090 | HTEM Pipe with socket DN/OD 40 x 1000 mm – white | |
| 559100 | HTEM Pipe with socket DN/OD 40 x 2000 mm – white | |
| 559120 | HTEM Pipe with socket DN/OD 50 x 150 mm – white | |
| 559130 | HTEM Pipe with socket DN/OD 50 x 250 mm – white | |
| 559140 | HTEM Pipe with socket DN/OD 50 x 500 mm – white | |
| 559150 | HTEM Pipe with socket DN/OD 50 x 1000 mm – white | |
| 559160 | HTEM Pipe with socket DN/OD 50 x 2000 mm – white | |
| 559300 | HTB Bend DN/OD 32 15° – white | |
| 559310 | HTB Bend DN/OD 32 30° – white | |
| 559320 | HTB Bend DN/OD 32 45° – white | |
| 559340 | HTB Bend DN/OD 32 87,5° – white | |
| 559350 | HTB Bend DN/OD 40 15° – white | |
| 559360 | HTB Bend DN/OD 40 30° – white | |
| 559370 | HTB Bend DN/OD 40 45° – white | |
| 559390 | HTB Bend DN/OD 40 87,5° – white | |
| 559400 | HTB Bend DN/OD 50 15° – white | |
| 559410 | HTB Bend DN/OD 50 30° – white | |
| 559420 | HTB Bend DN/OD 50 45° – white | |
| 559440 | HTB Bend DN/OD 50 87,5° – white | |
| 559600 | HTEA Branch DN/OD 32/ 32 45° – white | |
| 559610 | HTEA Branch DN/OD 40/ 40 45° – white | |
| 559620 | HTEA Branch DN/OD 50/ 50 45° – white | |
| 559660 | HTEA Branch DN/OD 32/32 87,5° – white | |
| 559670 | HTEA Branch DN/OD 50/50 87,5° – white | |
| 559680 | HTEA Branch DN/OD 40/40 87,5° – white | |
| 559700 | HTU Coupler DN/OD 32 – white | |
| 559710 | HTU Coupler DN/OD 40 – white | |
| 559720 | HTU Coupler DN/OD 50 – white | |
| 559750 | HTMM Double Socket DN/OD 32 – white | |
| 559760 | HTMM Double Socket DN/OD 40 – white | |
| 559770 | HTMM Double Socket DN/OD 50 – white | |
| 559800 | HTM Plug DN/OD 32 – white | |
| 559810 | HTM Plug DN/OD 40 – white | |
| 559820 | HTM Plug DN/OD 50 – white | |
| 559900 | HTR Reducer, eccentric DN/OD 40/ 32 – white | |
| 559910 | HTR Reducer, eccentric DN/OD 50/ 32 – white | |
| 559920 | HTR Reducer, eccentric DN/OD 50/ 40 – white |
| Item number | Name | Downloads |
|---|---|---|
| 220065 | KGEM Pipe with socket SN 10 Full wall DN/OD 110 x 500 mm | |
| 220110 | KGEM Pipe with socket SN 10 Full wall DN/OD 110 x 1000 mm | |
| 220130 | KGEM Pipe with socket SN 10 Full wall DN/OD 110 x 3000 mm | |
| 220160 | KGEM Pipe with socket SN 10 Full wall DN/OD 110 x 6000 mm | |
| 222110 | KGEM Pipe with socket SN 10 Full wall DN/OD 160 x 1000 mm | |
| 222130 | KGEM Pipe with socket SN 10 Full wall DN/OD 160 x 3000 mm | |
| 222160 | KGEM Pipe with socket SN 10 Full wall DN/OD 160 x 6000 mm | |
| 223110 | KGEM Pipe with socket SN 10 Full wall DN/OD 200 x 1000 mm | |
| 223130 | KGEM Pipe with socket SN 10 Full wall DN/OD 200 x 3000 mm | |
| 223160 | KGEM Pipe with socket SN 10 Full wall DN/OD 200 x 6000 mm | |
| 224110 | KGEM Pipe with socket SN 10 Full wall DN/OD 250 x 1000 mm | |
| 224130 | KGEM Pipe with socket SN 10 Full wall DN/OD 250 x 3000 mm | |
| 224160 | KGEM Pipe with socket SN 10 Full wall DN/OD 250 x 6000 mm | |
| 225110 | KGEM Pipe with socket SN 10 Full wall DN/OD 315 x 1000 mm | |
| 225130 | KGEM Pipe with socket SN 10 Full wall DN/OD 315 x 3000 mm | |
| 225160 | KGEM Pipe with socket SN 10 Full wall DN/OD 315 x 6000 mm | |
| 226110 | KGEM Pipe with socket SN 10 Full wall DN/OD 400 x 1000 mm | |
| 226130 | KGEM Pipe with socket SN 10 Full wall DN/OD 400 x 3000 mm | |
| 226160 | KGEM Pipe with socket SN 10 Full wall DN/OD 400 x 6000 mm | |
| 227110 | KGEM Pipe with socket SN 10 Full wall DN/OD 500 x 1000 mm | |
| 227130 | KGEM Pipe with socket SN 10 Full wall DN/OD 500 x 3000 mm | |
| 227160 | KGEM Pipe with socket SN 10 Full wall DN/OD 500 x 6000 mm |
| Item number | Name | Downloads |
|---|---|---|
| 222170 | KGEM Pipe with socket SN 8 Coex DN/OD 160 x 1000 mm | |
| 222180 | KGEM Pipe with socket SN 8 Coex DN/OD 160 x 3000 mm | |
| 222190 | KGEM Pipe with socket SN 8 Coex DN/OD 160 x 5000 mm | |
| 223170 | KGEM Pipe with socket SN 8 Coex DN/OD 200 x 1000 mm | |
| 223180 | KGEM Pipe with socket SN 8 Coex DN/OD 200 x 3000 mm | |
| 223190 | KGEM Pipe with socket SN 8 Coex DN/OD 200 x 5000 mm | |
| 224170 | KGEM Pipe with socket SN 8 Coex DN/OD 250 x 1000 mm | |
| 224180 | KGEM Pipe with socket SN 8 Coex DN/OD 250 x 3000 mm | |
| 224190 | KGEM Pipe with socket SN 8 Coex DN/OD 250 x 5000 mm | |
| 225170 | KGEM Pipe with socket SN 8 Coex DN/OD 315 x 1000 mm | |
| 225180 | KGEM Pipe with socket SN 8 Coex DN/OD 315 x 3000 mm | |
| 225190 | KGEM Pipe with socket SN 8 Coex DN/OD 315 x 5000 mm | |
| 226170 | KGEM Pipe with socket SN 8 Coex DN/OD 400 x 1000 mm | |
| 226180 | KGEM Pipe with socket SN 8 Coex DN/OD 400 x 3000 mm | |
| 226190 | KGEM Pipe with socket SN 8 Coex DN/OD 400 x 5000 mm | |
| 227180 | KGEM Pipe with socket SN 8 Coex DN/OD 500 x 3000 mm | |
| 227190 | KGEM Pipe with socket SN 8 Coex DN/OD 500 x 5000 mm |
| Item number | Name | Downloads |
|---|---|---|
| 220000 | KGEM Pipe with socket SN 4 Coex DN/OD 110 x 500 mm | |
| 220010 | KGEM Pipe with socket SN 4 Coex DN/OD 110 x 1000 mm | |
| 220020 | KGEM Pipe with socket SN 4 Coex DN/OD 110 x 2000 mm | |
| 220030 | KGEM Pipe with socket SN 4 Coex DN/OD 110 x 3000 mm | |
| 220050 | KGEM Pipe with socket SN 4 Coex DN/OD 110 x 5000 mm | |
| 220200 | KGB Bend DN/OD 110 15° | |
| 220210 | KGB Bend DN/OD 110 30° | |
| 220220 | KGB Bend DN/OD 110 45° | |
| 220230 | KGB Bend DN/OD 110 67° | |
| 220240 | KGB Bend DN/OD 110 87,5° | |
| 220300 | KGEA Branch DN/OD 110/110 45° | |
| 220310 | KGEA Triple Socket Branch DN/OD 110/110 45° | |
| 220400 | KGEA Branch DN/OD 110/110 87,5° | |
| 220410 | KGEA Triple Socket Branch DN/OD 110/110 87,5° | |
| 220500 | KGU Coupler DN/OD 110 | |
| 220510 | KGMM Double Socket DN/OD 110 | |
| 220600 | KGRE Inspection Pipe DN/OD 110 angular | |
| 220611 | KGRE Spare bolt for Inspection pipe DN/OD 110-200 | |
| 220620 | KGM Plug DN/OD 110 | |
| 220630 | KGK Cap DN/OD 110 | |
| 220640 | KGRE Inspection Pipe DN/OD 110 round | |
| 220810 | KGAM Single socket DN/OD 110 | |
| 220820 | KGUG Connection piece to cast-iron pipes DN/OD 110 (without gasket) | |
| 220830 | KGUS Connection piece to stoneware pipe (spigot end) DN/OD 110 (complete with gasket) | |
| 220840 | KGUSM Connection piece to stoneware pipe (socket) DN/OD 110 | |
| 221000 | KGEM Pipe with socket SN 4 Coex DN/OD 125 x 500 mm | |
| 221010 | KGEM Pipe with socket SN 4 Coex DN/OD 125 x 1000 mm | |
| 221020 | KGEM Pipe with socket SN 4 Coex DN/OD 125 x 2000 mm | |
| 221030 | KGEM Pipe with socket SN 4 Coex DN/OD 125 x 3000 mm | |
| 221050 | KGEM Pipe with socket SN 4 Coex DN/OD 125 x 5000 mm | |
| 221200 | KGB Bend DN/OD 125 15° | |
| 221210 | KGB Bend DN/OD 125 30° | |
| 221220 | KGB Bend DN/OD 125 45° | |
| 221230 | KGB Bend DN/OD 125 67° | |
| 221240 | KGB Bend DN/OD 125 87,5° | |
| 221300 | KGEA Branch DN/OD 125/125 45° | |
| 221310 | KGEA Branch DN/OD 125/110 45° | |
| 221400 | KGEA Branch DN/OD 125/125 87,5° | |
| 221410 | KGEA Branch DN/OD 125/110 87,5° | |
| 221500 | KGU Coupler DN/OD 125 | |
| 221510 | KGMM Double Socket DN/OD 125 | |
| 221600 | KGRE Inspection Pipe DN/OD 125 angular | |
| 221620 | KGM Plug DN/OD 125 | |
| 221630 | KGK Cap DN/OD 125 | |
| 221640 | KGRE Inspection Pipe DN/OD 125 round | |
| 221700 | KGR Reducer, eccentric DN/OD 125/110 | |
| 221830 | KGUS Connection piece to stoneware pipe (spigot end) DN/OD 125 (complete with gasket) | |
| 221840 | KGUSM Connection piece to stoneware pipe (socket) DN/OD 125 | |
| 222000 | KGEM Pipe with socket SN 4 Coex DN/OD 160 x 500 mm | |
| 222010 | KGEM Pipe with socket SN 4 Coex DN/OD 160 x 1000 mm | |
| 222020 | KGEM Pipe with socket SN 4 Coex DN/OD 160 x 2000 mm | |
| 222030 | KGEM Pipe with socket SN 4 Coex DN/OD 160 x 3000 mm | |
| 222050 | KGEM Pipe with socket SN 4 Coex DN/OD 160 x 5000 mm | |
| 222200 | KGB Bend DN/OD 160 15° | |
| 222210 | KGB Bend DN/OD 160 30° | |
| 222220 | KGB Bend DN/OD 160 45° | |
| 222230 | KGB Bend DN/OD 160 67° | |
| 222240 | KGB Bend DN/OD 160 87,5° | |
| 222300 | KGEA Branch DN/OD 160/160 45° | |
| 222310 | KGEA Branch DN/OD 160/125 45° | |
| 222320 | KGEA Branch DN/OD 160/110 45° | |
| 222400 | KGEA Branch DN/OD 160/160 87,5° | |
| 222410 | KGEA Branch DN/OD 160/125 87,5° | |
| 222420 | KGEA Branch DN/OD 160/110 87,5° | |
| 222500 | KGU Coupler DN/OD 160 | |
| 222510 | KGMM Double Socket DN/OD 160 | |
| 222600 | KGRE Inspection Pipe DN/OD 160 angular | |
| 222620 | KGM Plug DN/OD 160 | |
| 222630 | KGK Cap DN/OD 160 | |
| 222640 | KGRE Inspection Pipe DN/OD 160 round | |
| 222700 | KGR Reducer, eccentric DN/OD 160/110 | |
| 222710 | KGR Reducer, eccentric DN/OD 160/125 | |
| 222820 | KGUG Connection piece to cast-iron pipes DN/OD 160 (without gasket) | |
| 222830 | KGUS Connection piece to stoneware pipe (spigot end) DN/OD 160 (complete with gasket) | |
| 222840 | KGUSM Connection piece to stoneware pipe (socket) DN/OD 160 | |
| 223000 | KGEM Pipe with socket SN 4 Coex DN/OD 200 x 500 mm | |
| 223010 | KGEM Pipe with socket SN 4 Coex DN/OD 200 x 1000 mm | |
| 223020 | KGEM Pipe with socket SN 4 Coex DN/OD 200 x 2000 mm | |
| 223030 | KGEM Pipe with socket SN 4 Coex DN/OD 200 x 3000 mm | |
| 223050 | KGEM Pipe with socket SN 4 Coex DN/OD 200 x 5000 mm | |
| 223200 | KGB Bend DN/OD 200 15° | |
| 223210 | KGB Bend DN/OD 200 30° | |
| 223220 | KGB Bend DN/OD 200 45° | |
| 223230 | KGB Bend DN/OD 200 67° | |
| 223240 | KGB Bend DN/OD 200 87,5° | |
| 223300 | KGEA Branch DN/OD 200/200 45° | |
| 223310 | KGEA Branch DN/OD 200/160 45° | |
| 223320 | KGEA Branch DN/OD 200/125 45° | |
| 223330 | KGEA Branch DN/OD 200/110 45° | |
| 223400 | KGEA Branch DN/OD 200/200 87,5° | |
| 223410 | KGEA Branch DN/OD 200/160 87,5° | |
| 223430 | KGEA Branch DN/OD 200/110 87,5° | |
| 223500 | KGU Coupler DN/OD 200 | |
| 223510 | KGMM Double Socket DN/OD 200 | |
| 223600 | KGRE Inspection Pipe DN/OD 200 angular | |
| 223620 | KGM Plug DN/OD 200 | |
| 223630 | KGK Cap DN/OD 200 | |
| 223640 | KGRE Inspection Pipe DN/OD 200 round | |
| 223700 | KGR Reducer, eccentric DN/OD 200/160 | |
| 223830 | KGUS Connection piece to stoneware pipe (spigot end) DN/OD 200 (complete with gasket) | |
| 223840 | KGUSM Connection piece to stoneware pipe (socket) DN/OD 200 | |
| 224010 | KGEM Pipe with socket SN 4 Coex DN/OD 250 x 1000 mm | |
| 224020 | KGEM Pipe with socket SN 4 Coex DN/OD 250 x 2000 mm | |
| 224030 | KGEM Pipe with socket SN 4 Coex DN/OD 250 x 3000 mm | |
| 224050 | KGEM Pipe with socket SN 4 Coex DN/OD 250 x 5000 mm | |
| 224200 | KGB Bend DN/OD 250 15° | |
| 224210 | KGB Bend DN/OD 250 30° | |
| 224220 | KGB Bend DN/OD 250 45° | |
| 224240 | KGB Bend DN/OD 250 87,5° | |
| 224300 | KGEA Branch DN/OD 250/250 45° | |
| 224310 | KGEA Branch DN/OD 250/200 45° | |
| 224320 | KGEA Branch DN/OD 250/160 45° | |
| 224330 | KGEA Branch DN/OD 250/125 45° | |
| 224340 | KGEA Branch DN/OD 250/110 45° | |
| 224400 | KGEA Branch DN/OD 250/250 87,5° | |
| 224410 | KGEA Branch DN/OD 250/200 87,5° | |
| 224420 | KGEA Branch DN/OD 250/160 87,5° | |
| 224440 | KGEA Branch DN/OD 250/110 87,5° | |
| 224500 | KGU Coupler DN/OD 250 | |
| 224510 | KGMM Double Socket DN/OD 250 | |
| 224620 | KGM Plug DN/OD 250 | |
| 224630 | KGK Cap DN/OD 250 | |
| 224700 | KGR Reducer, eccentric DN/OD 250/200 | |
| 224830 | KGUS Connection piece to stoneware pipe (spigot end) DN/OD 250 (without gasket) | |
| 224840 | KGUSM Connection piece to stoneware pipe (socket) DN/OD 250 | |
| 225010 | KGEM Pipe with socket SN 4 Coex DN/OD 315 x 1000 mm | |
| 225020 | KGEM Pipe with socket SN 4 Coex DN/OD 315 x 2000 mm | |
| 225030 | KGEM Pipe with socket SN 4 Coex DN/OD 315 x 3000 mm | |
| 225050 | KGEM Pipe with socket SN 4 Coex DN/OD 315 x 5000 mm | |
| 225200 | KGB Bend DN/OD 315 15° | |
| 225210 | KGB Bend DN/OD 315 30° | |
| 225220 | KGB Bend DN/OD 315 45° | |
| 225240 | KGB Bend DN/OD 315 87,5° | |
| 225300 | KGEA Branch DN/OD 315/315 45° | |
| 225310 | KGEA Branch DN/OD 315/250 45° | |
| 225320 | KGEA Branch DN/OD 315/200 45° | |
| 225330 | KGEA Branch DN/OD 315/160 45° | |
| 225350 | KGEA Branch DN/OD 315/110 45° | |
| 225400 | KGEA Branch DN/OD 315/315 87,5° | |
| 225420 | KGEA Branch DN/OD 315/200 87,5° | |
| 225430 | KGEA Branch DN/OD 315/160 87,5° | |
| 225450 | KGEA Branch DN/OD 315/110 87,5° | |
| 225500 | KGU Coupler DN/OD 315 | |
| 225510 | KGMM Double Socket DN/OD 315 | |
| 225620 | KGM Plug DN/OD 315 | |
| 225630 | KGK Cap DN/OD 315 | |
| 225700 | KGR Reducer, eccentric DN/OD 315/250 | |
| 225830 | KGUS Connection piece to stoneware pipe (spigot end) DN/OD 315 (without gasket) | |
| 225840 | KGUSM Connection piece to stoneware pipe (socket) DN/OD 315 | |
| 226010 | KGEM Pipe with socket SN 4 Coex DN/OD 400 x 1000 mm | |
| 226020 | KGEM Pipe with socket SN 4 Coex DN/OD 400 x 2000 mm | |
| 226050 | KGEM Pipe with socket SN 4 Coex DN/OD 400 x 5000 mm | |
| 226200 | KGB Bend DN/OD 400 15° | |
| 226210 | KGB Bend DN/OD 400 30° | |
| 226220 | KGB Bend DN/OD 400 45° | |
| 226240 | KGB Bend DN/OD 400 87,5° | |
| 226300 | KGEA Branch DN/OD 400/400 45° | |
| 226310 | KGEA Branch DN/OD 400/315 45° | |
| 226320 | KGEA Branch DN/OD 400/250 45° | |
| 226330 | KGEA Branch DN/OD 400/200 45° | |
| 226340 | KGEA Branch DN/OD 400/160 45° | |
| 226400 | KGEA Branch DN/OD 400/400 87,5° | |
| 226420 | KGEA Branch DN/OD 400/250 87,5° | |
| 226440 | KGEA Branch DN/OD 400/160 87,5° | |
| 226500 | KGU Coupler DN/OD 400 | |
| 226510 | KGMM Double Socket DN/OD 400 | |
| 226620 | KGM Plug DN/OD 400 | |
| 226630 | KGK Cap DN/OD 400 | |
| 226700 | KGR Reducer, eccentric DN/OD 400/315 | |
| 227010 | KGEM Pipe with socket SN 4 Coex DN/OD 500 x 1000 mm | |
| 227020 | KGEM Pipe with socket SN 4 Coex DN/OD 500 x 2000 mm | |
| 227050 | KGEM Pipe with socket SN 4 Coex DN/OD 500 x 5000 mm | |
| 227200 | KGB Bend DN/OD 500 15° | |
| 227210 | KGB Bend DN/OD 500 30° | |
| 227220 | KGB Bend DN/OD 500 45° | |
| 227240 | KGB Bend DN/OD 500 87,5° | |
| 227300 | KGEA Branch DN/OD 500/500 45° | |
| 227320 | KGEA Branch DN/OD 500/315 45° | |
| 227340 | KGEA Branch DN/OD 500/200 45° | |
| 227350 | KGEA Branch DN/OD 500/160 45° | |
| 227400 | KGEA Branch DN/OD 500/500 87,5° | |
| 227420 | KGEA Branch DN/OD 500/315 87,5° | |
| 227450 | KGEA Branch DN/OD 500/160 87,5° | |
| 227500 | KGU Coupler DN/OD 500 | |
| 227620 | KGM Plug DN/OD 500 | |
| 227700 | KGR Reducer, eccentric DN/OD 500/400 | |
| 228070 | KGBD Bend 2M DN/OD 110 15° | |
| 228075 | KGBD Bend 2M DN/OD 110 30° | |
| 228080 | KGBD Bend 2M DN/OD 110 45° | |
| 228085 | KGBD Bend 2M SW DN/OD 110 87,5° | |
| 228088 | KGB Bend 1M SW DN/OD 110 87,5 ° | |
| 820900 | KGF Chamber lining DN/OD 110/110 | |
| 820910 | KGF Chamber lining DN/OD 110/240 | |
| 822900 | KGF Chamber lining DN/OD 160/110 | |
| 822910 | KGF Chamber lining DN/OD 160/240 | |
| 823900 | KGF Chamber lining DN/OD 200/110 | |
| 823910 | KGF Chamber lining DN/OD 200/240 | |
| 824600 | KGRE Inspection Pipe DN/OD 250 round | |
| 825600 | KGRE Inspection Pipe DN/OD 315 round | |
| 826600 | KGRE Inspection Pipe DN/OD 400 round | |
| 880060 | Lip seal DN 110 (KG) | |
| 880075 | Lip seal DN 125 (KG) | |
| 880090 | Lip seal DN 160 (KG) | |
| 880100 | Lip seal DN 200 (KG) | |
| 880110 | Lip seal DN 250 (KG) | |
| 880120 | Lip seal DN 315 (KG) | |
| 880130 | Lip seal DN 400 (KG) | |
| 880140 | Lip seal DN 500 (KG) | |
| 880260 | NBR Lip seal oil resistant DN 110 (KG/HT/Sk) | |
| 880275 | NBR Lip seal oil resistant DN 125 (KG/HT) | |
| 880290 | NBR Lip seal oil resistant DN 160 (KG/HT) | |
| 880300 | NBR Lip seal oil resistant DN 200 (KG) | |
| 880310 | NBR Lip seal oil resistant DN 250 (KG) | |
| 880320 | NBR Lip seal oil resistant DN 315 (KG) | |
| 880330 | NBR Lip seal oil resistant DN 400 (KG) | |
| 880340 | NBR Lip seal oil resistant DN 500 (KG) | |
| 880810 | Lip seal 2k Pro Diam DN/OD 110 (KG PVC SN8, SN10 and KG grey) | |
| 880815 | Lip seal 2k Pro Diam DN/OD 125 (KG PVC SN8, SN10 and KG grey) | |
| 880820 | Lip seal 2k Pro Diam DN/OD 160 (KG PVC SN8, SN10 and KG grey) | |
| 880825 | Lip seal 2k Pro Diam DN/OD 200 (KG PVC SN8, SN10 and KG grey) | |
| 880830 | Lip seal 2k Pro Diam DN/OD 250 (KG PVC SN8, SN10 and KG grey) | |
| 880835 | Lip seal 2k Pro Diam DN/OD 315 (KG PVC SN8, SN10 and KG grey) | |
| 880840 | Lip seal 2k Pro Diam DN/OD 400 (KG PVC SN8, SN10 and KG grey) | |
| 880845 | Lip seal 2k Pro Diam DN/OD 500 (KG PVC SN8, SN10 and KG grey) | |
| 881025 | GA gasket (cast iron) DN 110 | |
| 881040 | GA Set gasket DN 160 (KG, KG2000) | |
| 881100 | Profile gasket for KGUS DN 110 (KG, KG2000) | |
| 881110 | Profile gasket for KGUS DN 125 (KG, KG2000) | |
| 881120 | Profile gasket for KGUS DN 160 (KG, KG2000) | |
| 881130 | Profile gasket for KGUS DN 200 (KG) | |
| 881140 | Profile gasket for KGUS DN 250 (KG) | |
| 881150 | Profile gasket for KGUS DN 315 (KG) | |
| 881800 | Lubricant 150 g | |
| 881810 | Lubricant 250 g | |
| 881820 | Lubricant 500 g | |
| 881830 | Lubricant 1000 g | |
| 881840 | Lubricant 3000 g |
| Item number | Name | Downloads |
|---|---|---|
| 770320 | KG2000EM Pipe with socket SN 10 DN/OD 110 x 500 mm | |
| 770340 | KG2000EM Pipe with socket SN 10 DN/OD 110 x 1000 mm | |
| 770360 | KG2000EM Pipe with socket SN 10 DN/OD 110 x 2000 mm | |
| 770370 | KG2000EM Pipe with socket SN 10 DN/OD 110 x 3000 mm | |
| 770376 | KG2000EM Partial seepage pipe slotted DN/OD 110 x 3000 mm (Water entry area 165 cm²/m) | |
| 770380 | KG2000EM Pipe with socket SN 10 DN/OD 110 x 5000 mm | |
| 770385 | KG2000EM full seepage pipe slotted DN/OD 110 x 6000 mm (Water entry area 220 cm²/m) | |
| 770386 | KG2000EM Partial seepage pipe slotted DN/OD 110 x 6000 mm (Water entry area 165 cm²/m) | |
| 770387 | KG2000EM Multi-purpose pipe slotted DN/OD 110 x 6000 mm (Water entry area 110 cm²/m) | |
| 770388 | KG2000EM Multi-purpose pipe slotted DN/OD 110 x 6000 mm (Water entry area 166 cm²/m) | |
| 770390 | KG2000EM Multi-purpose pipe perforated DN/OD 110 x 5000 mm | |
| 770420 | KG2000EM Pipe with socket SN 10 DN/OD 125 x 500 mm | |
| 770440 | KG2000EM Pipe with socket SN 10 DN/OD 125 x 1000 mm | |
| 770460 | KG2000EM Pipe with socket SN 10 DN/OD 125 x 2000 mm | |
| 770470 | KG2000EM Pipe with socket SN 10 DN/OD 125 x 3000 mm | |
| 770480 | KG2000EM Pipe with socket SN 10 DN/OD 125 x 5000 mm | |
| 770490 | KG2000EM Multi-purpose pipe perforated DN/OD 125 x 5000 mm | |
| 770520 | KG2000EM Pipe with socket SN 10 DN/OD 160 x 500 mm | |
| 770540 | KG2000EM Pipe with socket SN 10 DN/OD 160 x 1000 mm | |
| 770560 | KG2000EM Pipe with socket SN 10 DN/OD 160 x 2000 mm | |
| 770570 | KG2000EM Pipe with socket SN 10 DN/OD 160 x 3000 mm | |
| 770576 | KG2000EM Partial seepage pipe slotted DN/OD 160 x 3000 mm (Water entry area 165 cm²/m) | |
| 770580 | KG2000EM Pipe with socket SN 10 DN/OD 160 x 5000 mm | |
| 770585 | KG2000EM full seepage pipe slotted DN/OD 160 x 6000 mm (Water entry area 220 cm²/m) | |
| 770586 | KG2000EM Partial seepage pipe slotted DN/OD 160 x 6000 mm (Water entry area 165 cm²/m) | |
| 770587 | KG2000EM Multi-purpose pipe slotted DN/OD 160 x 6000 mm (Water entry area 110 cm²/m) | |
| 770588 | KG2000EM Multi-purpose pipe slotted DN/OD 160 x 6000 mm (Water entry area 166 cm²/m) | |
| 770590 | KG2000EM Multi-purpose pipe perforated DN/OD 160 x 5000 mm | |
| 770620 | KG2000EM Pipe with socket SN 10 DN/OD 200 x 500 mm | |
| 770640 | KG2000EM Pipe with socket SN 10 DN/OD 200 x 1000 mm | |
| 770660 | KG2000EM Pipe with socket SN 10 DN/OD 200 x 2000 mm | |
| 770670 | KG2000EM Pipe with socket SN 10 DN/OD 200 x 3000 mm | |
| 770680 | KG2000EM Pipe with socket SN 10 DN/OD 200 x 5000 mm | |
| 770690 | KG2000EM Multi-purpose pipe perforated DN/OD 200 x 5000 mm | |
| 770740 | KG2000EM Pipe with socket SN 10 DN/OD 250 x 1000 mm | |
| 770770 | KG2000EM Pipe with socket SN 10 DN/OD 250 x 3000 mm | |
| 770790 | KG2000EM Pipe with socket SN 10 DN/OD 250 x 6000 mm | |
| 770840 | KG2000EM Pipe with socket SN 10 DN/OD 315 x 1000 mm | |
| 770870 | KG2000EM Pipe with socket SN 10 DN/OD 315 x 3000 mm | |
| 770890 | KG2000EM Pipe with socket SN 10 DN/OD 315 x 6000 mm | |
| 770940 | KG2000EM Pipe with socket SN 10 DN/OD 400 x 1000 mm | |
| 770970 | KG2000EM Pipe with socket SN 10 DN/OD 400 x 3000 mm | |
| 770990 | KG2000EM Pipe with socket SN 10 DN/OD 400 x 6000 mm | |
| 771040 | KG2000EM Pipe with socket SN 10 DN/OD 500 x 1000 mm | |
| 771070 | KG2000EM Pipe with socket SN 10 DN/OD 500 x 3000 mm | |
| 771090 | KG2000EM Pipe with socket SN 10 DN/OD 500 x 6000 mm | |
| 771100 | KG2000B Bend DN/OD 500 15° | |
| 771110 | KG2000B Bend DN/OD 500 30° | |
| 771120 | KG2000B Bend DN/OD 500 45° | |
| 771130 | KG2000EA Branch DN/OD 500/160 45° | |
| 771140 | KG2000EA Branch DN/OD 500/500 45° | |
| 771150 | KG2000EA Branch DN/OD 500/315 45° | |
| 771160 | KG2000U Coupler DN/OD 500 | |
| 771165 | KG2000U Coupler DN/OD 630 | |
| 771170 | KG2000MM Double Socket DN/OD 500 | |
| 771175 | KG2000MM Double Socket DN/OD 630 | |
| 771180 | KG2000M Plug DN/OD 500 | |
| 771190 | KG2000R Reducer, eccentric DN/OD 500/400 | |
| 771200 | KG2000B Bend DN/OD 630 15° | |
| 771215 | KG2000EA Branch without socket DN/OD 630/160 45° | |
| 771220 | KG2000B Bend DN/OD 630 45° | |
| 771235 | KG2000EA Branch without socket DN/OD 630/200 45° | |
| 771295 | KG2000R Reducer, eccentric DN/OD 630/500 | |
| 771300 | KG2000B Bend DN/OD 110 15° | |
| 771310 | KG2000B Bend DN/OD 110 30° | |
| 771320 | KG2000B Bend DN/OD 110 45° | |
| 771330 | KG2000B Bend DN/OD 110 67,5° | |
| 771350 | KG2000B Bend DN/OD 110 87,5° | |
| 771400 | KG2000B Bend DN/OD 125 15° | |
| 771410 | KG2000B Bend DN/OD 125 30° | |
| 771420 | KG2000B Bend DN/OD 125 45° | |
| 771430 | KG2000B Bend DN/OD 125 67,5° | |
| 771450 | KG2000B Bend DN/OD 125 87,5° | |
| 771500 | KG2000B Bend DN/OD 160 15° | |
| 771510 | KG2000B Bend DN/OD 160 30° | |
| 771520 | KG2000B Bend DN/OD 160 45° | |
| 771530 | KG2000B Bend DN/OD 160 67,5° | |
| 771550 | KG2000B Bend DN/OD 160 87,5° | |
| 771600 | KG2000B Bend DN/OD 200 15° | |
| 771610 | KG2000B Bend DN/OD 200 30° | |
| 771620 | KG2000B Bend DN/OD 200 45° | |
| 771655 | KG2000B Bend DN/OD 200 87,5° | |
| 771700 | KG2000B Bend DN/OD 250 15° | |
| 771710 | KG2000B Bend DN/OD 250 30° | |
| 771720 | KG2000B Bend DN/OD 250 45° | |
| 771750 | KG2000B Bend DN/OD 250 87,5° | |
| 771800 | KG2000B Bend DN/OD 315 15° | |
| 771810 | KG2000B Bend DN/OD 315 30° | |
| 771820 | KG2000B Bend DN/OD 315 45° | |
| 771850 | KG2000B Bend DN/OD 315 87,5° | |
| 771900 | KG2000B Bend DN/OD 400 15° | |
| 771910 | KG2000B Bend DN/OD 400 30° | |
| 771920 | KG2000B Bend DN/OD 400 45° | |
| 771950 | KG2000B Bend DN/OD 400 87,5° | |
| 772040 | KG2000EM Pipe with socket SN 10 DN/OD 630 x 1000 mm | |
| 772070 | KG2000EM Pipe with socket SN 10 DN/OD 630 x 3000 mm | |
| 772090 | KG2000EM Pipe with socket SN 10 DN/OD 630 x 6000 mm | |
| 772095 | KG2000GL Pipe without socket SN 10 DN/OD 630 x 6000 mm | |
| 772180 | KG2000M Plug DN/OD 630 | |
| 772330 | KG2000EA Branch DN/OD 110/110 45° | |
| 772340 | KG2000EA Branch DN/OD 125/110 45° | |
| 772350 | KG2000EA Branch DN/OD 160/110 45° | |
| 772360 | KG2000EA Branch DN/OD 200/110 45° | |
| 772440 | KG2000EA Branch DN/OD 125/125 45° | |
| 772450 | KG2000EA Branch DN/OD 160/125 45° | |
| 772550 | KG2000EA Branch DN/OD 160/160 45° | |
| 772560 | KG2000EA Branch DN/OD 200/160 45° | |
| 772660 | KG2000EA Branch DN/OD 200/200 45° | |
| 772760 | KG2000EA Branch DN/OD 250/160 45° | |
| 772770 | KG2000EA Branch DN/OD 250/250 45° | |
| 772850 | KG2000EA Branch DN/OD 315/160 45° | |
| 772860 | KG2000EA Branch DN/OD 315/200 45° | |
| 772880 | KG2000EA Branch DN/OD 315/315 45° | |
| 772940 | KG2000EA Branch DN/OD 400/160 45° | |
| 772960 | KG2000EA Branch DN/OD 400/200 45° | |
| 772970 | KG2000EA Branch DN/OD 400/315 45° | |
| 772990 | KG2000EA Branch DN/OD 400/400 45° | |
| 774330 | KG2000EA Branch DN/OD 110/110 87,5° | |
| 774350 | KG2000EA Branch DN/OD 160/110 87,5° | |
| 774440 | KG2000EA Branch DN/OD 125/125 87,5° | |
| 774550 | KG2000EA Branch DN/OD 160/160 87,5° | |
| 774630 | KG2000EA Branch DN/OD 200/110 87,5° | |
| 774660 | KG2000EA Branch DN/OD 200/160 87,5° | |
| 774750 | KG2000EA Branch DN/OD 250/160 87,5° | |
| 774770 | KG2000EA Branch DN/OD 250/250 87,5° | |
| 774850 | KG2000EA Branch DN/OD 315/160 87,5° | |
| 774880 | KG2000EA Branch DN/OD 315/315 87,5° | |
| 774940 | KG2000EA Branch DN/OD 400/160 87,5° | |
| 774970 | KG2000EA Branch DN/OD 400/315 87,5° | |
| 774990 | KG2000EA Branch DN/OD 400/400 87,5° | |
| 775340 | KG2000R Reducer, eccentric DN/OD 125/110 | |
| 775350 | KG2000R Reducer, eccentric DN/OD 160/110 | |
| 775450 | KG2000R Reducer, eccentric DN/OD 160/125 | |
| 775560 | KG2000R Reducer, eccentric DN/OD 200/160 | |
| 775670 | KG2000R Reducer, eccentric DN/OD 250/200 | |
| 775780 | KG2000R Reducer, eccentric DN/OD 315/250 | |
| 775880 | KG2000R Reducer, eccentric DN/OD 400/315 | |
| 777300 | KG2000MM Double Socket DN/OD 110 | |
| 777320 | KG2000M Plug DN/OD 110 | |
| 777380 | KG2000US Connection piece to stoneware pipe, spigot end DN/OD 110 | |
| 777390 | KG2000USM Connection piece to stoneware pipe, socket DN/OD 110 | |
| 777400 | KG2000MM Double Socket DN/OD 125 | |
| 777420 | KG2000M Plug DN/OD 125 | |
| 777480 | KG2000US Connection piece to stoneware pipe, spigot end DN/OD 125 | |
| 777500 | KG2000MM Double Socket DN/OD 160 | |
| 777520 | KG2000M Plug DN/OD 160 | |
| 777580 | KG2000US Connection piece to stoneware pipe, spigot end DN/OD 160 | |
| 777590 | KG2000USM Connection piece to stoneware pipe, socket DN/OD 160 | |
| 777600 | KG2000MM Double Socket DN/OD 200 | |
| 777620 | KG2000M Plug DN/OD 200 | |
| 777700 | KG2000MM Double Socket DN/OD 250 | |
| 777720 | KG2000M Plug DN/OD 250 | |
| 777800 | KG2000MM Double Socket DN/OD 315 | |
| 777820 | KG2000M Plug DN/OD 315 | |
| 777900 | KG2000MM Double Socket DN/OD 400 | |
| 777920 | KG2000M Plug DN/OD 400 | |
| 778300 | KG2000U Coupler DN/OD 110 | |
| 778310 | KG2000RE Inspection Pipe DN/OD 110 | |
| 778320 | KG2000UG Connection piece to cast-iron pipe DN/OD 110 (without gasket) | |
| 778400 | KG2000U Coupler DN/OD 125 | |
| 778410 | KG2000RE Inspection Pipe DN/OD 125 | |
| 778420 | KG2000UG Connection piece to cast-iron pipe DN/OD 125 (without gasket) | |
| 778500 | KG2000U Coupler DN/OD 160 | |
| 778510 | KG2000RE Inspection Pipe DN/OD 160 | |
| 778520 | KG2000UG Connection piece to cast-iron pipe DN/OD 160 (without gasket) | |
| 778600 | KG2000U Coupler DN/OD 200 | |
| 778610 | KG2000RE Inspection Pipe DN/OD 200 | |
| 778620 | KG2000UG Connection piece to cast-iron pipe DN/OD 200 (without gasket) | |
| 778700 | KG2000U Coupler DN/OD 250 | |
| 778800 | KG2000U Coupler DN/OD 315 | |
| 778900 | KG2000U Coupler DN/OD 400 | |
| 877570 | KG2000BA Connection to concrete pipe DN/OD 160 | |
| 877670 | KG2000BA Connection to concrete pipe DN/OD 200 | |
| 880400 | SBR Lip seal DN/OD 110 (KG2000, Skolan Safe pipes) | |
| 880410 | SBR Lip seal DN/OD 125 (KG2000) | |
| 880420 | SBR Lip seal DN/OD 160 (KG2000, Skolan Safe) | |
| 880430 | SBR Lip seal DN/OD 200 (KG2000, Skolan Safe) | |
| 880440 | SBR Lip seal DN/OD 250 (KG2000) | |
| 880450 | SBR Lip seal DN/OD 315 (KG2000) | |
| 880460 | SBR Lip seal DN/OD 400 (KG2000) | |
| 880470 | SBR Lip seal DN/OD 500 (KG2000) | |
| 880480 | SBR Lip seal DN/OD 630 (KG2000) | |
| 880500 | NBR Lip seal oil resistant DN/OD 110 (KG2000, Skolan Safe pipes) | |
| 880510 | NBR Lip seal oil resistant DN/OD 125 (KG2000) | |
| 880520 | NBR Lip seal oil resistant DN/OD 160 (KG2000, Skolan Safe) | |
| 880530 | NBR Lip seal oil resistant DN/OD 200 (KG2000, Skolan Safe) | |
| 880540 | NBR Lip seal oil resistant DN/OD 250 (KG2000) | |
| 880550 | NBR Lip seal oil resistant DN/OD 315 (KG2000) | |
| 880560 | NBR Lip seal oil resistant DN/OD 400 (KG2000) | |
| 880570 | NBR Lip seal oil resistant DN/OD 500 (KG2000) | |
| 880580 | NBR Lip seal oil resistant DN/OD 630 (KG2000) | |
| 881035 | GA Set gasket DN 125 (KG, KG200) | |
| 881055 | GA Set gasket DN 200 (KG, KG2000) | |
| 881650 | KG2000 Sealtape |
| Item number | Name | Downloads |
|---|---|---|
| 780340 | KG2000EM Pipe with socket DN/OD 110 x 1000 mm SN 16 | |
| 780370 | KG2000EM Pipe with socket DN/OD 110 x 3000 mm SN 16 | |
| 780390 | KG2000EM Pipe with socket DN/OD 110 x 6000 mm SN 16 | |
| 780440 | KG2000EM Pipe with socket DN/OD 125 x 1000 mm SN 16 | |
| 780470 | KG2000EM Pipe with socket DN/OD 125 x 3000 mm SN 16 | |
| 780490 | KG2000EM Pipe with socket DN/OD 125 x 6000 mm SN 16 | |
| 780540 | KG2000EM Pipe with socket DN/OD 160 x 1000 mm SN 16 | |
| 780570 | KG2000EM Pipe with socket DN/OD 160 x 3000 mm SN 16 | |
| 780590 | KG2000EM Pipe with socket DN/OD 160 x 6000 mm SN 16 | |
| 780640 | KG2000EM Pipe with socket DN/OD 200 x 1000 mm SN 16 | |
| 780670 | KG2000EM Pipe with socket DN/OD 200 x 3000 mm SN 16 | |
| 780690 | KG2000EM Pipe with socket DN/OD 200 x 6000 mm SN 16 | |
| 780740 | KG2000EM Pipe with socket DN/OD 250 x 1000 mm SN 16 | |
| 780770 | KG2000EM Pipe with socket DN/OD 250 x 3000 mm SN 16 | |
| 780790 | KG2000EM Pipe with socket DN/OD 250 x 6000 mm SN 16 | |
| 780840 | KG2000EM Pipe with socket DN/OD 315 x 1000 mm SN 16 | |
| 780870 | KG2000EM Pipe with socket DN/OD 315 x 3000 mm SN 16 | |
| 780890 | KG2000EM Pipe with socket DN/OD 315 x 6000 mm SN 16 | |
| 780940 | KG2000EM Pipe with socket DN/OD 400 x 1000 mm SN 16 | |
| 780970 | KG2000EM Pipe with socket DN/OD 400 x 3000 mm SN 16 | |
| 780990 | KG2000EM Pipe with socket DN/OD 400 x 6000 mm SN 16 | |
| 781040 | KG2000EM Pipe with socket DN/OD 500 x 1000 mm SN 16 | |
| 781070 | KG2000EM Pipe with socket DN/OD 500 x 3000 mm SN 16 | |
| 781090 | KG2000EM Pipe with socket DN/OD 500 x 6000 mm SN 16 | |
| 782040 | KG2000EM Pipe with socket DN/OD 630 x 1000 mm SN 16 | |
| 782070 | KG2000EM Pipe with socket DN/OD 630 x 3000 mm SN 16 | |
| 782090 | KG2000EM Pipe with socket DN/OD 630 x 6000 mm SN 16 | |
| 782095 | KG2000GL Pipe without socket DN/OD 630 x 6000 mm SN 16 | |
| 790540 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 160 x 1000 mm SN 16 | |
| 790570 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 160 x 3000 mm SN 16 | |
| 790590 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 160 x 6000 mm SN 16 | |
| 790640 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 200 x 1000 mm SN 16 | |
| 790670 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 200 x 3000 mm SN 16 | |
| 790690 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 200 x 6000 mm SN 16 | |
| 790740 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 250 x 1000 mm SN 16 | |
| 790770 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 250 x 3000 mm SN 16 | |
| 790790 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 250 x 6000 mm SN 16 | |
| 790840 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 315 x 1000 mm SN 16 | |
| 790870 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 315 x 3000 mm SN 16 | |
| 790890 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 315 x 6000 mm SN 16 | |
| 790940 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 400 x 1000 mm SN 16 | |
| 790970 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 400 x 3000 mm SN 16 | |
| 790990 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 400 x 6000 mm SN 16 | |
| 791040 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 500 x 1000 mm SN 16 | |
| 791070 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 500 x 3000 mm SN 16 | |
| 791090 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 500 x 6000 mm SN 16 | |
| 792040 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 630 x 1000 mm SN 16 | |
| 792070 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 630 x 3000 mm SN 16 | |
| 792090 | KG2000EM Rainwater (blue) Pipe with socket DN/OD 630 x 6000 mm SN 16 | |
| 792095 | KG2000GL Rainwater (blue) Pipe without socket DN/OD 630 x 6000 mm SN 16 |
| Item number | Name | Downloads |
|---|---|---|
| 669000 | PE-Pipe hard PN 12,5 20×2,0 mm 25 mtr./roll | |
| 669010 | PE-Pipe hard PN 12,5 20×2,0 mm 50 mtr./roll | |
| 669020 | PE-Pipe hard PN 12,5 20×2,0 mm 100 mtr./roll | |
| 669100 | PE-Pipe hard PN 12,5 25×2,3 mm 25 mtr./roll | |
| 669110 | PE-Pipe hard PN 12,5 25×2,3 mm 50 mtr./roll | |
| 669120 | PE-Pipe hard PN 12,5 25×2,3 mm 100 mtr./roll | |
| 669200 | PE-Pipe hard PN 12,5 32×3,0 mm 25 mtr./roll | |
| 669210 | PE-Pipe hard PN 12,5 32×3,0 mm 50 mtr./roll | |
| 669220 | PE-Pipe hard PN 12,5 32×3,0 mm 100 mtr./roll | |
| 669300 | PE-Pipe hard PN 12,5 40×3,7 mm 25 mtr./roll | |
| 669310 | PE-Pipe hard PN 12,5 40×3,7 mm 50 mtr./roll | |
| 669320 | PE-Pipe hard PN 12,5 40×3,7 mm 100 mtr./roll | |
| 669410 | PE-Pipe hard PN 12,5 50×4,6 mm 50 mtr./roll | |
| 669420 | PE-Pipe hard PN 12,5 50×4,6 mm 100 mtr./roll | |
| 669510 | PE-Pipe hard PN 12,5 63×5,8 mm 50 mtr./roll | |
| 669520 | PE-Pipe hard PN 12,5 63×5,8 mm 100 mtr./roll |
| Item number | Name | Downloads |
|---|---|---|
| 332000 | SKOLANsafeEM Pipe with socket DN/OD 58 x 150 mm | |
| 332010 | SKOLANsafeEM Pipe with socket DN/OD 58 x 250 mm | |
| 332020 | SKOLANsafeEM Pipe with socket DN/OD 58 x 500 mm | |
| 332040 | SKOLANsafeEM Pipe with socket DN/OD 58 x 1000 mm | |
| 332060 | SKOLANsafeEM Pipe with socket DN/OD 58 x 2000 mm | |
| 332070 | SKOLANsafeEM Pipe with socket DN/OD 58 x 3000 mm | |
| 332080 | SKOLANsafeGL Pipe without socket DN/OD 58 x 3000 mm | |
| 332100 | SKOLANsafeB Bend DN/OD 58 15° | |
| 332110 | SKOLANsafeB Bend DN/OD 58 30° | |
| 332120 | SKOLANsafeB Bend DN/OD 58 45° | |
| 332130 | SKOLANsafeB Bend DN/OD 58 67,5° | |
| 332140 | SKOLANsafeB Bend DN/OD 58 87,5° | |
| 332200 | SKOLANsafeEA Branch DN/OD 58/58 45° | |
| 332300 | SKOLANsafeEA Branch DN/OD 58/58 67,5° | |
| 332400 | SKOLANsafeEA Branch DN/OD 58/58 87,5° | |
| 332500 | SKOLANsafeU Coupler DN/OD 58 | |
| 332510 | SKOLANsafeMM Double socket DN/OD 58 | |
| 332600 | SKOLANsafeRE Inspection pipe DN/OD 58 | |
| 332620 | SKOLANsafeM Plug DN/OD 58 | |
| 332750 | SKOLANsafe Reducer HT DN/OD 58/40 | |
| 332810 | SKOLANsafeAM Single socket, Adapter for SML connection DN/OD 58 | |
| 333000 | SKOLANsafeEM Pipe with socket DN/OD 78 x 150 mm | |
| 333010 | SKOLANsafeEM Pipe with socket DN/OD 78 x 250 mm | |
| 333020 | SKOLANsafeEM Pipe with socket DN/OD 78 x 500 mm | |
| 333040 | SKOLANsafeEM Pipe with socket DN/OD 78 x 1000 mm | |
| 333060 | SKOLANsafeEM Pipe with socket DN/OD 78 x 2000 mm | |
| 333070 | SKOLANsafeEM Pipe with socket DN/OD 78 x 3000 mm | |
| 333080 | SKOLANsafeGL Pipe without socket DN/OD 78 x 3000 mm | |
| 333100 | SKOLANsafeB Bend DN/OD 78 15° | |
| 333110 | SKOLANsafeB Bend DN/OD 78 30° | |
| 333120 | SKOLANsafeB Bend DN/OD 78 45° | |
| 333130 | SKOLANsafeB Bend DN/OD 78 67,5° | |
| 333140 | SKOLANsafeB Bend DN/OD 78 87,5° | |
| 333200 | SKOLANsafeEA Branch DN/OD 78/78 45° | |
| 333210 | SKOLANsafeEA Branch DN/OD 78/58 45° | |
| 333300 | SKOLANsafeEA Branch DN/OD 78/78 67,5° | |
| 333310 | SKOLANsafeEA Branch DN/OD 78/58 67,5° | |
| 333400 | SKOLANsafeEA Branch DN/OD 78/78 87,5° | |
| 333410 | SKOLANsafeEA Branch DN/OD 78/58 87,5° | |
| 333500 | SKOLANsafeU Coupler DN/OD 78 | |
| 333510 | SKOLANsafeMM Double socket DN/OD 78 | |
| 333600 | SKOLANsafeRE Inspection pipe DN/OD 78 | |
| 333620 | SKOLANsafeM Plug DN/OD 78 | |
| 333710 | SKOLANsafeR Reducerer DN/OD 78/58 | |
| 333750 | SKOLANsafe Reducer HT DN/OD 78/50 | |
| 333810 | SKOLANsafeAM Single socket, Adapter for SML connection DN/OD 78 | |
| 333830 | SKOLANsafe Connection to HT Safe DN/OD 75 | |
| 333900 | SKOLANsafeDA Double branch DN/OD 78/78/78 87,5° | |
| 334000 | SKOLANsafeEM Pipe with socket DN/OD 90 x 150 mm | |
| 334010 | SKOLANsafeEM Pipe with socket DN/OD 90 x 250 mm | |
| 334020 | SKOLANsafeEM Pipe with socket DN/OD 90 x 500 mm | |
| 334040 | SKOLANsafeEM Pipe with socket DN/OD 90 x 1000 mm | |
| 334060 | SKOLANsafeEM Pipe with socket DN/OD 90 x 2000 mm | |
| 334070 | SKOLANsafeEM Pipe with socket DN/OD 90 x 3000 mm | |
| 334080 | SKOLANsafeGL Pipe without socket DN/OD 90 x 3000 mm | |
| 334100 | SKOLANsafeB Bend DN/OD 90 15° | |
| 334110 | SKOLANsafeB Bend DN/OD 90 30° | |
| 334120 | SKOLANsafeB Bend DN/OD 90 45° | |
| 334140 | SKOLANsafeB Bend DN/OD 90 87,5° | |
| 334200 | SKOLANsafeEA Branch DN/OD 90/90 45° | |
| 334210 | SKOLANsafeEA Branch DN/OD 90/78 45° | |
| 334220 | SKOLANsafeEA Branch DN/OD 90/58 45° | |
| 334230 | SKOLANsafeEA Branch DN/OD 90/50 45° Transition to HT Safe | |
| 334400 | SKOLANsafeEA Branch DN/OD 90/90 87,5° | |
| 334410 | SKOLANsafeEA Branch DN/OD 90/78 87,5° | |
| 334420 | SKOLANsafeEA Branch DN/OD 90/58 87,5° | |
| 334430 | SKOLANsafeEA Branch DN/OD 90/50 87,5° Transition to HT Safe | |
| 334500 | SKOLANsafeU Coupler DN/OD 90 | |
| 334510 | SKOLANsafeMM Double socket DN/OD 90 | |
| 334600 | SKOLANsafeRE Inspection pipe DN/OD 90 | |
| 334620 | SKOLANsafeM Plug DN/OD 90 | |
| 334670 | SKOLANsafeDDA Double branch for showers 90° DN/OD 90/90/58 | |
| 334680 | SKOLANsafeDDA Double branch for showers 90° left DN/OD 90/90/58 | |
| 334690 | SKOLANsafeDDA Double branch for showers 90° right DN/OD 90/90/58 | |
| 334710 | SKOLANsafeR Reducerer DN/OD 90/78 | |
| 334720 | SKOLANsafeR Reducerer DN/OD 90/58 | |
| 334810 | SKOLANsafeAM Single socket, Adapter for SML connection DN/OD 90 | |
| 334900 | SKOLANsafeDA Double branch DN/OD 90/90/90 87,5° (swept)* | |
| 334910 | SKOLANsafeED Double corner branch DN/OD 90/90/90 87,5° | |
| 335000 | SKOLANsafeEM Pipe with socket DN/OD 110 x 150 mm | |
| 335010 | SKOLANsafeEM Pipe with socket DN/OD 110 x 250 mm | |
| 335020 | SKOLANsafeEM Pipe with socket DN/OD 110 x 500 mm | |
| 335040 | SKOLANsafeEM Pipe with socket DN/OD 110 x 1000 mm | |
| 335060 | SKOLANsafeEM Pipe with socket DN/OD 110 x 2000 mm | |
| 335070 | SKOLANsafeEM Pipe with socket DN/OD 110 x 3000 mm | |
| 335080 | SKOLANsafeGL Pipe without socket DN/OD 110 x 3000 mm | |
| 335100 | SKOLANsafeB Bend DN/OD 110 15° | |
| 335110 | SKOLANsafeB Bend DN/OD 110 30° | |
| 335120 | SKOLANsafeB Bend DN/OD 110 45° | |
| 335130 | SKOLANsafeB Bend DN/OD 110 67,5° | |
| 335140 | SKOLANsafeB Bend DN/OD 110 87,5° | |
| 335145 | SKOLANsafeB Bend DN/OD 110 87,5° with inspection/door | |
| 335200 | SKOLANsafeEA Branch DN/OD 110/110 45° | |
| 335210 | SKOLANsafeEA Branch DN/OD 110/78 45° | |
| 335220 | SKOLANsafeEA Branch DN/OD 110/58 45° | |
| 335230 | SKOLANsafeEA Branch DN/OD 110/90 45° | |
| 335240 | SKOLANsafeEA Branch DN/OD 110/50 45° Transition to HT Safe | |
| 335300 | SKOLANsafeEA Branch DN/OD 110/110 67,5° | |
| 335310 | SKOLANsafeEA Branch DN/OD 110/78 67,5° | |
| 335320 | SKOLANsafeEA Branch DN/OD 110/58 67,5° | |
| 335400 | SKOLANsafeEA Branch DN/OD 110/110 87,5° | |
| 335405 | SKOLANsafeEA Branch DN/OD 110/110 87,5° with inspection/door | |
| 335410 | SKOLANsafeEA Branch DN/OD 110/78 87,5° | |
| 335420 | SKOLANsafeEA Branch DN/OD 110/58 87,5° | |
| 335430 | SKOLANsafeEA Branch DN/OD 110/90 87,5° | |
| 335440 | SKOLANsafeEA Branch DN/OD 110/50 87,5° Transition to HT Safe | |
| 335500 | SKOLANsafeU Coupler DN/OD 110 | |
| 335510 | SKOLANsafeMM Double socket DN/OD 110 | |
| 335600 | SKOLANsafeRE Inspection pipe DN/OD 110 | |
| 335620 | SKOLANsafeM Plug DN/OD 110 | |
| 335670 | SKOLANsafeDDA Double branch for showers 90° DN/OD 110/110/58 | |
| 335680 | SKOLANsafeDDA Double branch for showersh 90° left DN/OD 110/110/58 | |
| 335690 | SKOLANsafeDDA Double branch for showers 90° right DN/OD 110/110/58 | |
| 335700 | SKOLANsafeR Reducerer DN/OD 110/90 | |
| 335710 | SKOLANsafeR Reducerer DN/OD 110/78 | |
| 335720 | SKOLANsafeR Reducerer DN/OD 110/58 | |
| 335810 | SKOLANsafeAM Single socket, Adapter for SML connection DN/OD 110 | |
| 335900 | SKOLANsafeDA Double branch DN/OD 110/110/110 87,5° (swept)* | |
| 335910 | SKOLANsafeED Double corner branch DN/OD 110/110/110 87,5° | |
| 335920 | SKOLANsafePA Parallel branch DN/OD 110/110 | |
| 335930 | SKOLANsafeL Long socket DN/OD 110 | |
| 335935 | SKOLANsafeM Plug DN/OD 110 with inspection/door | |
| 335940 | SKOLANsafeSW Siphon bend DN/OD 58/40 | |
| 335960 | SKOLANsafeLB Long bend DN/OD 110 45° | |
| 335975 | SKOLANsafeEP Corner branch DN/OD 110/110/78 87,5° left | |
| 335985 | SKOLANsafeEP Corner branch DN/OD 110/110/78 87,5° right | |
| 336000 | SKOLANsafeEM Pipe with socket DN/OD 135 x 150 mm | |
| 336010 | SKOLANsafeEM Pipe with socket DN/OD 135 x 250 mm | |
| 336020 | SKOLANsafeEM Pipe with socket DN/OD 135 x 500 mm | |
| 336040 | SKOLANsafeEM Pipe with socket DN/OD 135 x 1000 mm | |
| 336060 | SKOLANsafeEM Pipe with socket DN/OD 135 x 2000 mm | |
| 336070 | SKOLANsafeEM Pipe with socket DN/OD 135 x 3000 mm | |
| 336080 | SKOLANsafeGL Pipe without socket DN/OD 135 x 3000 mm | |
| 336100 | SKOLANsafeB Bend DN/OD 135 15° | |
| 336110 | SKOLANsafeB Bend DN/OD 135 30° | |
| 336120 | SKOLANsafeB Bend DN/OD 135 45° | |
| 336140 | SKOLANsafeB Bend DN/OD 135 87,5° | |
| 336200 | SKOLANsafeEA Branch DN/OD 135/135 45° | |
| 336210 | SKOLANsafeEA Branch DN/OD 135/110 45° | |
| 336400 | SKOLANsafeEA Branch DN/OD 135/135 87,5° | |
| 336410 | SKOLANsafeEA Branch DN/OD 135/110 87,5° | |
| 336500 | SKOLANsafeU Coupler DN/OD 135 | |
| 336510 | SKOLANsafeMM Double socket DN/OD 135 | |
| 336600 | SKOLANsafeRE Inspection pipe DN/OD 135 | |
| 336620 | SKOLANsafeM Plug DN/OD 135 | |
| 336710 | SKOLANsafeR Reducerer DN/OD 135/110 | |
| 336810 | SKOLANsafeAM Single socket, Adapter for SML connection DN/OD 135 | |
| 336820 | SKOLANsafe Connection to HT Safe/KG DN/OD 125 | |
| 337000 | SKOLANsafeEM Pipe with socket DN/OD 160 x 150 mm | |
| 337010 | SKOLANsafeEM Pipe with socket DN/OD 160 x 250 mm | |
| 337020 | SKOLANsafeEM Pipe with socket DN/OD 160 x 500 mm | |
| 337040 | SKOLANsafeEM Pipe with socket DN/OD 160 x 1000 mm | |
| 337060 | SKOLANsafeEM Pipe with socket DN/OD 160 x 2000 mm | |
| 337070 | SKOLANsafeEM Pipe with socket DN/OD 160 x 3000 mm | |
| 337080 | SKOLANsafeGL Pipe without socket DN/OD 160 x 3000 mm | |
| 337100 | SKOLANsafeB Bend DN/OD 160 15° | |
| 337110 | SKOLANsafeB Bend DN/OD 160 30° | |
| 337120 | SKOLANsafeB Bend DN/OD 160 45° | |
| 337140 | SKOLANsafeB Bend DN/OD 160 87,5° | |
| 337200 | SKOLANsafeEA Branch DN/OD 160/160 45° | |
| 337210 | SKOLANsafeEA Branch DN/OD 160/110 45° | |
| 337400 | SKOLANsafeEA Branch DN/OD 160/160 87,5° | |
| 337410 | SKOLANsafeEA Branch DN/OD 160/110 87,5° | |
| 337500 | SKOLANsafeU Coupler DN/OD 160 | |
| 337510 | SKOLANsafeMM Double socket DN/OD 160 | |
| 337600 | SKOLANsafeRE Inspection pipe DN/OD 160 | |
| 337620 | SKOLANsafeM Plug DN/OD 160 | |
| 337700 | SKOLANsafeR Reducerer DN/OD 160/135 | |
| 337710 | SKOLANsafeR Reducerer DN/OD 160/110 | |
| 337810 | SKOLANsafeAM Single socket, Adapter for SML connection DN/OD 160 | |
| 338000 | SKOLANsafeEM Pipe with socket DN/OD 200 x 150 mm | |
| 338010 | SKOLANsafeEM Pipe with socket DN/OD 200 x 250 mm | |
| 338020 | SKOLANsafeEM Pipe with socket DN/OD 200 x 500 mm | |
| 338040 | SKOLANsafeEM Pipe with socket DN/OD 200 x 1000 mm | |
| 338060 | SKOLANsafeEM Pipe with socket DN/OD 200 x 2000 mm | |
| 338070 | SKOLANsafeEM Pipe with socket DN/OD 200 x 3000 mm | |
| 338080 | SKOLANsafeGL Pipe without socket DN/OD 200 x 3000 mm | |
| 338100 | SKOLANsafeB Bend DN/OD 200 15° | |
| 338110 | SKOLANsafeB Bend DN/OD 200 30° | |
| 338120 | SKOLANsafeB Bend DN/OD 200 45° | |
| 338150 | SKOLANsafeB Bend DN/OD 200 87,5° | |
| 338200 | SKOLANsafeEA Branch DN/OD 200/200 45° | |
| 338210 | SKOLANsafeEA Branch DN/OD 200/160 45° | |
| 338230 | SKOLANsafeEA Branch DN/OD 200/110 45° | |
| 338410 | SKOLANsafeEA Branch DN/OD 200/160 87,5° | |
| 338430 | SKOLANsafeEA Branch DN/OD 200/110 87,5° | |
| 338500 | SKOLANsafeU Coupler DN/OD 200 | |
| 338510 | SKOLANsafeMM Double socket DN/OD 200 | |
| 338600 | SKOLANsafeRE Inspection pipe DN/OD 200 | |
| 338620 | SKOLANsafeM Plug DN/OD 200 | |
| 338710 | SKOLANsafeR Reducerer DN/OD 200/160 | |
| 338810 | SKOLANsafeAM Single socket DN/OD 200 | |
| 339975 | Skolan Safe Floortrap DN 110 | |
| 839010 | Skolan Safe safety clamps for plugs DN 58 | |
| 839020 | Skolan Safe safety clamps for plugs DN 78 | |
| 839030 | Skolan Safe safety clamps for plugs DN 90 | |
| 839040 | Skolan Safe safety clamps for plugs DN 110 | |
| 839050 | Skolan Safe safety clamps for plugs DN 135 | |
| 839060 | Skolan Safe safety clamps for plugs DN 160 | |
| 839070 | Skolan Safe safety clamps for plugs DN 200 | |
| 880605 | Lip seal DN 58 (Skolan Safe) | |
| 880615 | Lip seal DN 78 (HT Safe) | |
| 880645 | Lip seal DN 135 (Skolan Safe) | |
| 880705 | NBR Lip seal oil resistant DN 58 (Skolan Safe) | |
| 880715 | NBR Lip seal oil resistant DN 78 (Skolan Safe) | |
| 880745 | NBR Lip seal oil resistant DN 135 (Skolan Safe) | |
| 881505 | Pull-out protection DN 58 (Skolan Safe) | |
| 881515 | Pull-out protection DN 78 (Skolan Safe) | |
| 881520 | Pull-out protection DN 90 (HT, Skolan Safe) | |
| 881535 | Pull-out protection DN 110 | |
| 881545 | Pull-out protection DN 135 (Skolan Safe) | |
| 881555 | Pull-out protection DN 160 | |
| 881565 | Pull-out protection DN/OD 200 (Sksafe) | |
| 910833 | SKOLANsafe Transition sleeve Skolan Safe 58 / HT Safe 50 mm |
| Item number | Name | Downloads |
|---|---|---|
| 660000 | SC 400 chamber base straight DN/OD 110 | |
| 660010 | SC 400 chamber base right-middle-left DN/OD 110 | |
| 660020 | SC 400 chamber base straight DN/OD 160 | |
| 660030 | SC 400 chamber base right-middle-left DN/OD 160 | |
| 660040 | SC 400 chamber base straight DN/OD 200 | |
| 660050 | SC 400 chamber base right-middle-left DN/OD 200 | |
| 660060 | SC 400 chamber base straight DN/OD 250 | |
| 660070 | SC 400 chamber base right-middle-left DN/OD 250 | |
| 660080 | SC 400 chamber base straight DN/OD 315 | |
| 660090 | SC 400 chamber base right-middle-left DN/OD 315 | |
| 660095 | SC 400 chamber base straight DN/OD 400 | |
| 660100 | PVC Riser pipe DN/OD 400 500 mm | |
| 660110 | PVC Riser pipe DN/OD 400 800 mm | |
| 660120 | PVC Riser pipe DN/OD 400 1000 mm | |
| 660130 | PVC Riser pipe DN/OD 400 1250 mm | |
| 660140 | PVC Riser pipe DN/OD 400 1500 mm | |
| 660150 | PVC Riser pipe DN/OD 400 2000 mm | |
| 660200 | PVC Telescopic cover DN/OD 315 B 125 (12,5 t) SV without ventilation | |
| 660205 | PP Telescopic cover DN/OD 315 B 125 (12,5 t) SV without ventilation (green) | |
| 660210 | PVC Telescopic cover DN/OD 315 B 125 (12,5 t) SV with ventilation | |
| 660215 | PP Telescopic cover DN/OD 315 B 125 (12,5 t) SV with ventilation (green) | |
| 660220 | PVC Telescopic cover DN/OD 315 D 400 (40 t) Surface water proof and backwater-proof | |
| 660235 | PVC Telescopic cover DN/OD 315 D 400 (40 t) Square Manhole cover | |
| 660240 | PVC Telescopic cover DN/OD 315 D 400 (40 t) SV without ventilation | |
| 660245 | PVC Telescopic cover DN/OD 315 D 400 (40 t) SV with ventilation | |
| 660250 | Manhole cover DN/OD 400 (plastic) A15 (1,5 t) | |
| 660260 | Concrete rim for telescopic cover DN/OD 315 | |
| 660265 | PP Telescopic cover DN/OD 315 D 400 (40 t) SV with ventilation (green) | |
| 660270 | Dirt trap DN/OD 315 | |
| 660275 | PP Telescopic cover DN/OD 315 D 400 (40 t) Surface water proof and backwater-proof (green) | |
| 660280 | Manhole cover DN/OD 400 (cast iron) A15 (1,5 t) | |
| 660285 | PP Telescopic cover DN/OD 315 D 400 (40 t) SV without ventilation (green) | |
| 660290 | PP Telescopic cover DN/OD 315 D 400 (40 t) Square Manhole cover (green) | |
| 660300 | Spare gasket DN/OD 400 | |
| 660520 | Combi manhole cover (round) DN/OD 400 Concrete B 125 and cast iron (12,5t) without ventilation | |
| 660600 | PP Riser pipe DN/OD 400 500 mm | |
| 660610 | PP Riser pipe DN/OD 400 800 mm | |
| 660620 | PP Riser pipe DN/OD 400 1000 mm | |
| 660630 | PP Riser pipe DN/OD 400 1250 mm | |
| 660640 | PP Riser pipe DN/OD 400 1500 mm | |
| 660650 | PP Riser pipe DN/OD 400 2000 mm | |
| 661205 | PP Telescopic cover DN/OD 315 B 125 (12,5 t) SV without ventilation (blue) | |
| 661215 | PP Telescopic cover DN/OD 315 B 125 (12,5 t) SV with ventilation (blue) | |
| 661265 | PP Telescopic cover DN/OD 315 D 400 (40 t) SV with ventilation (blue) | |
| 661275 | PP Telescopic cover DN/OD 315 D 400 (40 t) Surface water proof and backwater-proof (blue) | |
| 661285 | PP Telescopic cover DN/OD 315 D 400 (40 t) SV without ventilation (blue) | |
| 661290 | PP Telescopic cover DN/OD 315 D 400 (40 t) Square Manhole cover (blue) |
| Item number | Name | Downloads |
|---|---|---|
| 661000 | SC 600 chamber base straight DN/OD 160 | |
| 661010 | SC 600 chamber base cross DN/OD 160 | |
| 661020 | SC 600 chamber base straight DN/OD 200 | |
| 661030 | SC 600 chamber base cross DN/OD 200 | |
| 661040 | SC 600 chamber base straight DN/OD 250 | |
| 661050 | SC 600 chamber base cross DN/OD 250 | |
| 661060 | SC 600 chamber base straight DN/OD 315 | |
| 661070 | SC 600 chamber base cross DN/OD 315 | |
| 661080 | SC 600 chamber base straight DN/OD 400 | |
| 661110 | Ridged riser pipe DN 600 1000 mm | |
| 661120 | Ridged riser pipe DN 600 2000 mm | |
| 661130 | Ridged riser pipe DN 600 3000 mm | |
| 661160 | Ridged riser pipe DN 600 6000 mm | |
| 661200 | Telescopic adapter DN 600 Class B 125 (with gasket) | |
| 661220 | Telescopic adapter DN 600 Class D 400 (with gasket) | |
| 661250 | Telescopic cover A 15 DN 600 (with gasket) | |
| 661260 | Concrete support ring DN 600 | |
| 661350 | Replacement sealing collar DN 600 for chamber base/riser pipe/double socket for riser pipe DN 600 | |
| 661360 | Replacement sealing collar DN 600 for adapter DN 600 and telescope adapter A 15 DN 600 | |
| 661500 | SC 600 chamber base bend DN/OD 160 150° (210°) | |
| 661510 | SC 600 chamber base bend DN/OD 160 135° (225°) | |
| 661520 | SC 600 chamber base bend DN/OD 160 120° (240°) | |
| 661530 | SC 600 chamber base bend DN/OD 160 90° (270°) | |
| 661600 | SC 600 chamber base bend DN/OD 200 150° (210°) | |
| 661610 | SC 600 chamber base bend DN/OD 200 135° (225°) | |
| 661620 | SC 600 chamber base bend DN/OD 200 120° (240°) | |
| 661630 | SC 600 chamber base bend DN/OD 200 90° (270°) | |
| 661700 | Double socket for riser pipe DN 600 | |
| 662030 | SC 600 chamber base right-middle-left DN/OD 160 | |
| 662050 | SC 600 chamber base right-middle-left DN/OD 200 |
Sujeto a cambios técnicos.
